Optic A1 Yellow

OPTIC | PLAYFUL PRECISION:
With 140mm/125mm of travel, the 2024 Optic condenses years of technology from long travel bikes into a lightweight package that’s as ready to tear up climbs as it is tackling challenging descents. The VPSHP suspension layout provides increased rearward axle path and an idler to manage pedal feedback, keeping Optic’s playful roots, while punching above its weight when the trails get rough.

Specifications

FRAME	Optic Aluminum, 125mm Travel, High Pivot Horst Suspension, UDH, Hangerless Interface Compatible, Ride Aligned™
FORK	RockShox Pike Ultimate Charger 3, DebonAir+, 140mm, 44mm Offset, Fender Included
REAR SHOCK	Fox FLOAT X Performance Elite, 2 Pos, 185x50mm Trunnion
HEADSET	FSA #57 E Sealed Bearing
GRIPS	Ergon GD10 EVO Lock On
HANDLE BAR	6061 Alloy, 800mm, 25mm Rise
STEM	Alloy, 40mm Length, 35mm Clamp
SEAT POST	TranzX YS105 Dropper, 34.9mm, 150mm (1), 170mm (2), 200mm (3, 4), 230mm (5)
SEAT POST CLAMP	Norco Alloy Nutted Clamp
SADDLE	SDG Bel Air V3
FRONT BRAKE	SRAM Level Stealth Silver, 4-Piston, Sintered Pads
REAR BRAKE	SRAM Level Stealth Silver, 4-Piston, Sintered Pads
BRAKE LEVERS	SRAM Level Silver Stealth
SHIFTER REAR	SRAM Pod Ultimate Controller
REAR DERAILLEUR	SRAM GX Eagle AXS T-Type
CASSETTE	SRAM Eagle T-Type 1275, 10-52T
CHAIN	SRAM GX Eagle T-Type
CRANKSET	SRAM GX Eagle T-Type, 30T, 170mm
BOTTOM BRACKET	SRAM DUB BSA Threaded
CHAIN TENSIONER	Norco Idler Guide and Lower Guide
FRONT HUB	DT Swiss 350, 12x110mm Boost, 6-Bolt
REAR HUB	DT Swiss 350, 36T Ratchet, 12x148mm Boost, XD, 6-Bolt
SPOKES/NIPPLES	Black Stainless
RIMS	Stan's Flow S2, Black 32H, 29"
FRONT TIRE	Maxxis Minion DHF 2.5" 3C, MaxxTerra / EXO / TR, Folding
REAR TIRE	Maxxis Dissector 2.4" 3C, MaxxTerra / EXO / TR Folding
SEALANT	Stan's Sealant - 200ml
VALVES	Stan's Universal 35mm Presta Stem
RIM TAPE	Stan's Rim Tape
