Process 24 Microshift Green

The kids are alright. Better than alright. In fact, they’re so incredibly talented that we had to make a bike to keep up with the insane progression the groms are throwing on the trails these days. The Process 24 pulls cues from the adult-sized bikes and is ready to rip the local singletrack or the bike park’s rowdiest lines. The Process 24 features an air-sprung 120mm travel fork and shock and 100mm of rear travel, making it ready for hits big and small. A 10-speed 1x drivetrain and hydraulic disc brakes make for excellent control up and down the hill. The Process 24 is the perfect bike for your future prodigy!

Specifications

Component	Specification
Frame Material	Kona 6061 DH Aluminum Butted
Sizes	13"
Rear Shock	RockShox Deluxe Select Solo Air
Fork	Manitou Machete J-Unit Comp Air 120mm Tapered
Crankarms	FSA Alpha Drive
Chainrings	30t
Bottom Bracket (B/B)	FSA BB7420
Pedals	Kona JS2
Chain	KMC X10
Cassette	Microshift Advent X 11-48t 10spd
Chainguide	n/a
Front Derailleur (F/D)	n/a
Rear Derailleur (R/D)	Microshift Advent X
Shifters	Microshift Advent X
Brake Calipers	SRAM Level
Front Brake Rotor	SRAM Centerline 180mm
Rear Brake Rotor	SRAM Centerline 160mm
Brake Levers	SRAM Level
Headset	FSA No.57B
Handlebar	Kona OB
Stem	Kona OB
Seatpost	Kona Thumb OB 31.6mm
Seat Clamp	Kona Clamp
Grips	Kona Key Grip
Saddle	Kona DJ
Front Hub	Formula 110x15mm
Rear Hub	Formula 148x12mm
Spokes	Stainless Black 14g
Rims	Alex DM24
Front Tire	Kenda Kinetics Rear 24x2.35"
Rear Tire	Kenda Kinetics Rear 24x2.35"
Paint Color	Gloss Kiwi w/ Charcoal & Cyan Decals

Geometry

	Size	S
1	ST Length	332
2	TT Length	497
3	Reach	370
4	Stack	513
5	Standover	670
6	HT Angle	67
7	HT Length	90
8	ST Angle	74.5
9	CS Length	415
10	BB Drop	5
11	BB Height	315
12	Wheelbase	1043
13	Front Center	628
14	Fork Length	475
15	Fork Offset	39
